Khoom nthuav dav
Kev Txhim Kho Zoo
Tag nrho series ntawm portable ntsia hlau compressors txais EU IIIA cav, uas yog ntau zog-txuag thiab ib puag ncig-phooj ywg. Cov cua ducts ntawm no series ntawm diesel portable cua compressors tau tsim thiab optimized, thiab lub diesel muffler yog muab tso rau hauv lub ywj siab chav tsev nyob rau hauv lub tom qab kawg ntawm lub txias txias, uas ua kom lub txias txias thiab txo cov suab nrov ntawm cov khoom los ntawm 40%. .
Tag nrho cov khoom lag luam tau hloov kho dua tshiab nrog cov ncej muaj zog dua, kev tiv thaiv kev sib tw zoo dua thiab kev nyab xeeb, thiab lub ru tsev muaj zog muaj peev xwm nqa tau nrog cov roj hmab tiv thaiv strips, uas tuaj yeem ua tau raws li cov neeg siv khoom xav tau.
Intelligent Control System
Lub tshuab hluav taws xob diesel uas tau tsav lub tshuab cua compressor kuj muaj qhov kev tswj xyuas ntse, suav nrog kev tswj tsis siv neeg thiab kev tiv thaiv, kev ua yuam kev tsis muaj peev xwm, nqa cov khoom kim heev microcomputer fluorescent tswj vaj huam sib luag, tuaj yeem pom cov ntaub ntawv hloov pauv.
Patented filtering ntaus ntawv
Qhov no series ntawm diesel portable cua compressors yog tshwj xeeb uas tsim los rau φ115mm drilling rigs, thauj tog rau nkoj drilling rigs, slurry spraying rigs thiab txhua yam ntawm cov cua qhov yuav tsum tau los ntawm engineering mines. Lub cav diesel uas tau tsav lub tshuab cua compressors kuj tau txais patented tsim ntawm kev nyab xeeb huab cua lim cov cuab yeej thiab stainless hlau inlet yeeb nkab, uas ua kom lub peev xwm lim dej ntawm cov plua plav, thiab zoo dua tiv thaiv cov pa phem los ntawm kev tsim tawm vim kev puas tsuaj ntawm cov roj hmab hose.
Txhua lub siab hoses txuas nrog cov kav hlau, uas muaj kev sib khi zoo thiab tiv thaiv cov roj hmab los ntawm kev laus thiab tsis txhob hnav, tsis tsuas yog cov tsos zoo nkauj, tab sis kuj yog qhov zoo.
Specifications
Lub siab ntau ntawm no mobile diesel cua compressor yog 1. Nws txais Cummins lossis Yuchai cav. Nws tuaj yeem hloov kho rau txhua qhov huab cua qhov chaw siab tshaj plaws (tsim rau kev siv qhov siab siab tshaj 5500m).
|
Technical Specification |
||||
|
Qauv |
Nominal Siab |
F.A.D (Free Air Delivery) |
Disel zog |
Unit Dmensions (tag nrho) (L x W x H) |
|
|
Mpa |
m³/min |
kW/Hp |
cm |
|
Kev kub siab series |
||||
|
40 TSI |
0.6 |
4.2 |
37/50 |
240X133X148 |
|
58SCY-8ob log |
0.8 |
7 |
58/80 |
314X174X190 |
|
110SCY-84 lub log |
0.8 |
12 |
110/150 |
312X163X229 |
|
110SCY-10t-wheels |
1 |
12 |
110/150 |
289X202X227 |
|
110SCY-104 lub log |
1 |
12 |
110/150 |
312X163X229 |
|
110SCY-14.5 ob lub log |
1.45 |
10 |
110/150 |
289X202X227 |
|
110SCY-14.5 plaub log |
1.45 |
10 |
110/150 |
312X163X229 |
|
138SCY-14.5 ob lub log |
1.45 |
13 |
140/180 |
335X206X235 |
|
139SCY-134 lub log |
1.3 |
15 |
140/180 |
365X170X204 |
|
141SCY-134 lub log |
1.3 |
15.5 |
140/180 |
365X170X204 |
|
180SCY-84 lub log |
0.8 |
20 |
179/240 |
372X197X225 |
|
Low/middile siab series |
||||
|
168SCY-174 lub log |
1.7 |
16 |
162/220 |
362X195X220 |
|
177SCY-174 lub log |
1.7 |
16 |
177/240 |
372X197X225 |
|
181SCY-17ob log |
1.8 |
17 |
181/260 |
360X187X266 |
|
186SCY-184 lub log |
1.8 |
18 |
191/260 |
360X187X266 |
|
198SCY-184 lub log |
1.8 |
18 |
191/260 |
372X197X255 |
|
250SCY-18 plaub lub log (highland) |
1.8 |
23 |
295/400 |
381X200X290 |
|
220 SCY-21 |
2.1 |
20 |
221/300 |
380X187X255 |
|
300 SCY-24 |
2.4 |
30 |
309/420 |
415X195X290 |
Daim ntawv thov
Qhov no mobile diesel cua compressor siv lub ntswj ntsia hlau compressor, paub txog nws lub zog, txuag hluav taws xob, thiab tsawg zaus tsis ua hauj lwm. Txoj kev no pom muaj ntau daim ntawv thov thoob plaws ntau lub mines, kev tsim kho dej hauv av, kev tshem tawm lub caij nplooj ntoos hlav kub, thiab hauv kev ua cov roj thiab roj.
Shipping & Them Nyiaj
Txhua daim ntawm Miningwell cov cuab yeej thiab cov khoom siv drilling tau dhau los ua kev kuaj xyuas kev nyab xeeb kom ruaj ntseg ntawm cov khoom thauj hauv lub thawv.
Peb txoj kev them nyiaj: credit card, L / C, T / T, Western Union, thiab peb txhawb nqa shipping los ntawm huab cua thiab hiav txwv.
Cim npe nrov: 4 log 15 bar diesel portable ntsia hlau zoo cua compressor, Tuam Tshoj plaub log 15 bar diesel portable ntsia hlau zoo cua compressor manufacturers, lwm tus neeg, Hoobkas
