Khoom nthuav dav
- Lub npe: D Miningwell
- Yam tsawg kawg nkaus kom muaj nuj nqis: 1set
- Ntim cov ntsiab lus: txheem export ntim
-
Lub sij hawm xa tuaj: 15 mus rau 20 hnub
Daim ntawv cog lus them nyiaj: L / C, T / T, Western Union
Lub tshuab nqus dej hauv av tuaj yeem xaiv qhov 1-16 electrode ntsuas channel, uas tsis tsuas yog daws qhov teeb meem ntawm lub ntuj hluav taws xob hloov pauv txhua lub sijhawm, thiab zam qhov yuam kev los ntawm kev txav cov electrode ntau zaus hauv tib qhov profile, qhov tseeb tus nqi yog 30-60% siab dua qhov dav dav ib leeg-channel, thiab daws qhov tsis txaus ntawm cov twj paj nruag ib leeg kom rov ntsuas qhov ntsuas ntawm cov ntaub ntawv profile. Lub tshuab nqus dej hauv av ADMT-300SX-16D tuaj yeem xaiv lub wireless sojntsuam lossis dej tshawb nrhiav hoop qws thiab tuaj yeem hloov cov qauv ntsuas ntawm MN electrode thiab TT sojntsuam, uas tsis yog yooj yim thiab yooj yim rau kev khiav lag luam, tab sis kuj ceev heev rau kev ntsuas, uas feem ntau lees paub los ntawm cov neeg siv khoom.
Qhov zoo
High precision thiab muaj zog tiv thaiv kev cuam tshuam
Cov tub ntxhais module ntawm qhov ntsuas tau txais ib pob kev sib xyaw ua ke, nrog kev ua haujlwm siab thiab ua kom zoo heev los tiv thaiv kev cuam tshuam.
Lub ntsuas dej sib sib zog nqus hauv av nruab nrog lub tshuab ua haujlwm siab kom khiav ntau yam algorithms, cov zis yog ruaj khov thiab muaj tseeb kom ntseeg tau qhov tseeb ntawm cov cuab yeej hauv ntau qhov chaw.
Tsis siv neeg kos duab
Tom qab kev ntsuas tiav, 2D, 3D daim ntawv qhia xim thiab ntau hom duab nkhaus yuav raug tsim.
Kev ua haujlwm yooj yim nrog 10.1-inch kov npo ntawm kev ntsuas dua.
Kawm ua haujlwm borewell underground dej ntes hauv 5 feeb
Multi-screen sib qhia cov ntaub ntawv
Lub xov tooj ntawm tes, ntsuas, khoos phis tawj, chaw taws teeb tswj cov ntaub ntawv sib qhia, tsuas yog yuav tsum tau nkag mus rau hauv tib tus account thiab cov dej hauv av finder tshuab txhawb cov ntaub ntawv sib koom ntawm ntau tus account.
Patented technology
Tau txais ntau yam kev tsim patents
Patent No.:
ZL201310205318.9
ZL201110454869.X
ZL201320054153.5
Specifications
|
Versions |
ADMT-300SX-16D |
ADMT-500SX-16D |
ADMT-1200SX-16D |
ADMT-2000SX-16D |
ADMT-3000SX-16D |
|
Max Qhov tob (m) |
Tsawg dua los yog sib npaug li 300 |
Tsawg dua los yog sib npaug li 500 |
Tsawg dua los yog sib npaug li 1200 |
Tsawg dua los yog sib npaug li 2000 |
Tsawg dua los yog sib npaug li 3000 |
|
Channel nkag |
16 channels ntawm ib txhij input nrog tus qauv electrode qhov sib nrug ntawm 2.5m, thiab xaiv qhov sib txawv ntawm 5m, 7.5m, lossis 10m |
||||
|
Channel xaiv |
1-14 |
||||
|
Kev xaiv qhov tob |
Yeem nyob rau hauv qhov siab tshaj plaws qhov tob, xa mus rau 100/200/300/400/500/600/800/1200/2000/3000m |
||||
|
Tshawb xyuas lub sijhawm |
10-80 |
||||
|
Kev sib txuas |
Serial chaw nres nkoj, Wifi, Bluetooth 4.0, USB (yeem 4G) |
||||
|
Zaub |
10. |
||||
|
OS |
Android 6 0.1 |
||||
|
CPU |
ARM Cortex-A7 8-core CPU 2.0Hz |
||||
|
GPU |
OpenGL ES 2 0 |
||||
|
Cov yam ntxwv tseem ceeb |
Ntau qhov kev xaiv ntawm qhov tob, 2D / 3D plotting, tshem tau roj teeb |
||||
|
Sensing Hom |
MN/TT |
||||
|
Ntau zaus (hz) |
1-8K |
0.01-6K |
|||
|
Lim |
Preset lossis ntse xaiv zaus, analog + cov ntaub ntawv lim dej 1-16 zaug superposition xaiv tau |
||||
|
Kev ntxub ntxaug. |
0.1mV ± 3% |
0.01mV ± 2% |
|||
|
Lub Sijhawm Tau Txais (s) |
60-3600 |
120-5400 |
|||
|
Roj teeb |
800mA / H |
||||
|
Console Nyhav |
1, 85kg |
||||
Daim ntawv thov
Peb lub tshuab nrhiav dej ADMT-300SX-16D yog ib tus neeg muag khoom kub hauv Chile, thiab ntau tus neeg siv khoom tau siv qhov project drilling. Txhawm rau txhawm rau tho qhov kom raug, lawv xaiv D Miningwell tus dej nrhiav.
Shipping & Them Nyiaj
Txhua daim ntawm Miningwell cov cuab yeej thiab cov khoom siv drilling tau dhau los ua kev kuaj xyuas kev nyab xeeb kom ruaj ntseg ntawm cov khoom thauj hauv lub thawv.
Peb txoj kev them nyiaj muaj xws li credit card, L / C, T / T, Western Union, thiab peb txhawb nqa shipping los ntawm huab cua thiab hiav txwv.
Cim npe nrov: Suav teb sib sib zog nqus dej ntes 300m, Tuam Tshoj sib sib zog nqus dej hauv av ntes 300m manufacturers, lwm tus neeg, Hoobkas
