Specifications
|
Technical Parameters (Low Pressure Drill Bit) |
|||||
|
Qauv: |
Gauge khawm (mm) |
Pem hauv ntej khawm (mm) |
Tail shank txoj kab uas hla (mm) |
Chaw nres nkoj qhov |
Qhov hnyav (KG) |
|
CIR 76-76 |
φ12*5 |
φ12*3 |
φ43 |
2 |
2.1 |
|
CIR 90-90 |
φ14*6 |
φ13*2+φ12*2 |
φ53.5 |
2 |
3.7 |
|
CIR 90-110 |
φ14*6 |
φ13*3+φ12*3 |
φ53.5 |
3 |
4.6 |
|
CIR 90-130 |
φ14*7 |
φ13*3+φ12*4 |
φ53.5 |
3 |
6 |
|
CIR 110-110 |
φ14*6 |
φ13*3+φ12*3 |
φ64 |
3 |
6 |
|
CIR 110-130 |
φ14*7 |
φ13*3+φ12*4 |
φ64 |
3 |
7.4 |
|
CIR 110-150 |
φ14*8 |
φ14*3+φ13*6 |
φ64 |
3 |
9.6 |
|
CIR 110-170 |
φ15*9 |
φ14*6+φ13*10 |
φ64 |
3 |
12.3 |
|
CIR 110-200 |
φ15*9 |
φ14*6+φ13*12 |
φ64 |
3 |
16.5 |
|
CIR 150-150 |
φ16*9 |
φ14*6+φ14*4 |
φ89.5 |
3 |
14.8 |
|
CIR 150-175 |
φ16*9 |
φ14*6+φ14*5 |
φ89.5 |
3 |
19 |
|
CIR 170-175 |
φ16*9 |
φ14*6+φ14*5 |
φ102 |
3 |
21 |
|
CIR 170-185 |
φ16*9 |
φ14*6+φ14*6 |
φ102 |
3 |
21.8 |
Khoom nthuav dav
- Lub npe: miningwell
- Ntawv pov thawj: CE, ISO
- Yam tsawg kawg nkaus kom muaj nuj nqis: 1set
- Ntim cov ntsiab lus: txheem export ntim
- Lub sij hawm xa tuaj: 7-10 hnub
- Cov nqe lus them nqi: L / C, T / T, Western Union
Cov qauv dav dav ntawm cov khoom siv laum suav nrog cov cuab yeej siv siab tsawg hauv qhov ntau thiab tsawg 90-90 thiab 90-120, nruab nrab-siab laum khoom, thiab cov cuab yeej siv siab 3 ntiv tes, 4 ntiv tes, thiab 5 ntiv tes loj.
Ntawm lawv, eccentric laum cov khoom, los ntawm txoj kev ntawm lawv txoj kab uas hla loj dua thiab cov qauv yooj yim ntawm lub qhov, tau txais kev nyiam nyob rau hauv ntau yam kev siv vim kev lag luam thiab cov neeg siv khoom zoo. Lub eccentric laum me ntsis suav nrog qauv 45A-146, 90-108, thiab 110-127.
Lub concentric laum me ntsis system siv ib qho ingenious thiab yooj yim concentric voj voog txoj kev xyaum los ntawm lub npog casing. Lub concentric dth hammers thiab khawm cov khoom tuaj yeem laum qhov ntawm txhua lub kaum sab xis (xws li kab rov tav kev taw qhia) mus rau qhov tob ntawm ntau tshaj 100 meters. Vim tias cov phab ntsa ntawm cov laum sab nraud ntawm qhov sib npaug ntawm qhov sib xyaw ua ke yog tuab dua, qhov cuam tshuam hluav taws xob sib kis tau zoo ntawm tib lub qhov taub txoj kab uas hla kev tsim kho tsis zoo li qhov ntawm cov laum eccentric. Tsuas yog thaum lub qhov taub loj dua, cov nyhuv zoo dua.
Qhov zoo
Peb cov dth rauj laum khoom muaj qhov zoo hauv qab no:
1. 95% zoo sib xws nrog lub ntiaj teb sab saum toj hom xws li Atlas Copco.
2. Muaj peev xwm ntau lawm ntawm cov cuab yeej drilling.
3. nruj zoo tswj.
Qhov zoo ntawm D Miningwell siab siab dth khawm khoom:
1) Lub neej ntev ntawm lub laum me ntsis: cov khoom siv alloy, lub neej ua haujlwm ntev, zoo dua li cov khoom zoo sib xws;
2) Kev ua haujlwm siab drilling: cov hniav laum yog hnav-tiv taus, uas ua rau lub laum me ntsis ntse txhua lub sijhawm, yog li txhim kho qhov drilling ceev;
3) ruaj khov drilling ceev: lub laum me ntsis scrapes thiab txiav cov pob zeb tawg;
4) Kev ua tau zoo: D Miningwell high-pressure dth hammers thiab dth khawm cov khoom yog hnav-tiv taus thiab muaj txoj kab uas hla zoo tiv thaiv, uas ua rau cov hniav txiav kom siv tau zoo;
5) Kev siv ntau yam: kev xyaum tau ua pov thawj tias qhov me me yog tsim rau drilling carbonate pob zeb, limestone, chalk, av nplaum pob zeb, siltstone, sandstone thiab lwm yam mos thiab tawv (9 theem ntawm drillability) pob zeb, pob zeb nyuaj, piv nrog cov xyaum zoo tib yam. cov khoom, tshwj xeeb tshaj yog nyob rau hauv qib 6-8 ntawm cov pob zeb drilling nyhuv yog qhov tseem ceeb.
Shipping & Them Nyiaj
Txhua daim ntawm Miningwell cov cuab yeej thiab cov khoom siv drilling tau dhau los ua kev kuaj xyuas kev nyab xeeb kom ruaj ntseg ntawm cov khoom thauj hauv lub thawv.
Peb txoj kev them nyiaj: credit card, L / C, T / T, Western Union, thiab peb txhawb nqa shipping los ntawm huab cua thiab hiav txwv.
Cim npe nrov: down the hole laum ntsis, Tuam Tshoj down lub qhov laum ntsis manufacturers, lwm tus neeg, Hoobkas
