Hydraulic Crawler Dej Dej Zoo Drilling Rig

 一,

Dab tsi yog hydraulic crawler dej zoo drilling rig?

Crawler dej txaus drilling rig yog ib hom kev siv hluav taws xob nrog kev sib tsoo, xws li cov pa hluav taws xob drilling, thiab lwm yam tuaj yeem hloov kho ntau yam, los ntawm cov xuab zeb txheej, pebble txheej rau hard pob zeb tsim.} muaj cov dej num tag nrho, ua kom zoo tshaj plaws rau kev lag luam thiab ua liaj ua teb dej.

2,

Crawler dej txaus drilling rig composition qauv

1.} crawler chassis

Nws muaj zog tawm ntawm txoj kev muaj zog thiab haum rau cov roob, toj roob hauv pes, av nkos thiab lwm qhov chaw .

Cov kab hlau los yog cov kab hlau roj hmab yog xaiv tau, thiab qee tus qauv txhawb nqa 360℃hauv-situ kauj .

2. ncu ntauwd

Nws tuaj yeem tsa tau tsa thiab txo qis thiab qaij kom yooj yim los saib ntsug lossis av khawb;

Nws feem ntau muaj stroke ntawm 2-6 meters thiab tuaj yeem nruab nrog lub tshuab tsis siv neeg puas siv hluav taws xob {}}

3.} Cav fais fab pob

Nws yog feem ntau tsav los ntawm lub cav diesel muab lub zog rau cov khoom siv hydraulic thiab cov khoom siv cov khoom siv ntawm tag nrho cov cuab yeej;

Lub zog hluav taws xob feem ntau yog feem ntau ntawm 60-200 kw .

4.} drilling system

Nws suav nrog lub taub hau teb / lub taub hau fais fab (teb lub taub hau), deth), ib qho av nkos, thiab lwm yam};

Nws txhawb ntau yam ntawm cov txheej txheem drilling: huab cua drilling, av nkos drilling, thiab sib xyaw ua si drilling .

5. hydraulic System

Kev tswj hwm kev nqa, rov ua dua, kev sib hloov, taug kev, cov kev coj ua thiab lwm yam kev ua ntawm cov derrick;
High-art Cov teeb tsa tuaj yeem nruab nrog load hnov ​​cov thev naus laus zis (thauj khoom siv) thiab kev tswj hwm ib feem.

6.} Tswj System

Muab faib ua kev tuav tes kev hydraulic, hluav taws xob tswj khoom thiab chaw taws teeb tswj;
Cov qauv high-kawg yog nruab nrog cov cuab yeej ntse xws li kov cov ntxaij vab tshaus xws li cov ntxaij vab tshaus xws li cov sensors, qhov tob gauges, etc.



3,

Cov Qauv Tseem Ceeb (piv txwv)

4,

Qhov Zoo

Siab efficiency: Nrawm drilling ceev thiab txo qis qis dua vim muaj zog hydraulic thiab ruaj khov kev kawm .

Tsawg Zog Kev Siv: Kev khiav hauj lwm yooj yim Txo phau ntawv ua haujlwm, txhim kho cov khoom lag luam thiab kev nyab xeeb .

Durability & kev cia siab: Ua nrog high-qib kev ua haujlwm, kom muaj kev ua haujlwm ntev rau hauv cov chaw tawv muaj zog .

Yooj yim txij nkawm: Modular Destre tso cai rau kev yooj yim ua kev pabcuam thiab cov chaw hloov .

Nqi-Zoo: Muab cov nqi sib npaug ntawm cov nqi sib npaug, qhov zoo tshaj plaws rau cov neeg cog lus thiab tsoomfwv txoj kev txhim kho dej kev txhim kho cov haujlwm.



5,

Cov Kev Siv Raug Raug

Dej zoo drilling (hauv tsev, ua liaj ua teb, muaj)

Geothermal ris boreholes

Kev Tshawb Nrhiav Kev Dhawb

Kev Ua Si Hauv Nroog thiab Cov Dej Nyob Sab Nraud

Kev puas tsuaj kev puas tsuaj thiab cov dej num thaum muaj xwm ceev



6,

Raug sib piv: Crawler vs tsheb mounted

7,结语

Crawler dej txaus drilling Rig yog cov khoom siv zoo rau cov dej muaj zog, kev txhim kho chaw nyob hauv ntiaj teb, nws qhov kev tsim kho nyob deb li qub

Yog tias koj yuav tsum pom zoo cov qauv tsim nyog, lossis xav tau kev tsim kho cua, koj tuaj yeem muab cov khoom siv ua tiav thiab kuv tuaj yeem muab cov tshuaj tsim kho kom zoo rau koj .









• Hom Lub Npe: Miningwell
• Ntawv pov thawj: CE, ISO
• Yam tsawg kawg txiav txim kom muaj nuj nqis: 1 teeb
• Pob cov ntsiab lus: 40HQ-20 gp
• Lub sij hawm xa tuaj: 15-20 hnub
• Cov ntsiab lus them nqi: L / C, T / T, Western Union



Cov multi-lub tog raj kheej los ntawm nto moo lub Hoobkas tsim cov kev pab cuam lub neej tshwj xeeb, nrog rau kev tswj hwm huab cua hauv lub neej diesel hydraulic, yooj yim rau kev ua haujlwm .



Qhov no crawling zoo cov khoom siv roj except specetter chasab thiab cov tshuab hluav taws xob tsis muaj peev xwm ua tau zoo thiab hloov chaw ua ke tawm, muaj peev xwm hloov kho thiab hloov chaw tso tawm ua ke raws li drilling cov rods thiab submerged rauj kom paub tseeb thiab txhim khu kev qha ntawm cov tshuab xyaum thiab txo qhov rauj thiab txo qhov kev ua haujlwm siab ua haujlwm {}}







MW350 Crawler Mounted Laum Rig yog qhov kev siv hluav taws xob, thiab ntau yam kev siv hluav taws xob, thiab ntau yam kev siv hluav taws xob, thiab ntau yam kev lag luam hluav taws xob rau cov khoom siv dej kom qhuav {}}







NoHydraulic Crawler Dej Dej Zoo Drilling Rigmuaj peev xwm ua qhov sib txawv hauv cov kab sib txawv, thiab lub cev muaj zog ntawm lub zog hydraulic thiab nws yog hydraulic ntawm lub zog hydraulic, nrog rau propelling quab yuam.

MW 350 TAWB HYDRAULIC CRAWLER DEJ QHOV CHAW DRILLING RIG
Qhov hnyav (t)	8.6	Tho Yeeb Nkab Tshuab (hli)	Φ89 Φ102
Lub qhov taub uas hla (hli)	140-325	Laum Yeeb Ncauj Ntev (m)	1.5m 2.0m 3.0m 6.0m
DRILLING qhov tob (m)	350	Rig nqa khoom quab yuam (T)	22
Ib-zaug ua ntej ntev (m)	6.6	Kev nce nrawm nrawm (M / min)	18
Taug kev ceev (KM / H)	2.5	Kev Pub Ceev Ceev Ceev (M / min)	33
Nce Toj Kaum (Max.)	30	Dav ntawm chaw thau khoom (m)	2.7
Sau capacitor (KW)	92	Hoisting lub zog ntawm winch (t)	2
Siv Cua Siab (Mpa)	1.7-3.4	VIAV VIAV TORATE (n . m)	6200-8500
Kev Siv Cua (MLP / min)	17-36	Dimension (mm)	6000×2000×2550
Viav Vias Ceev (RPM)	66-135	Nruab nrog rauj	Nruab nrab thiab muaj cua siab series
Lub Nkag Mus Ua Haujlwm (M / H)	15-35	Kev mob siab ceg tawv (m)	1.4
Lub cav hom	Yuchai cav
