Specifications
|
Parameter |
Chav tsev |
MW7 ╱360B Ⅸ | |
|
Drilling muaj peev xwm |
Drilling qhov tob |
m |
700 |
|
Max. txoj kab uas hla ntawm kev ua haujlwm hauv pem teb |
mm |
500 |
|
|
Pub noj system |
Max. liting peev |
kN kev |
360 |
|
Max. pub muaj peev xwm |
kN kev |
120 |
|
|
Max. lifting ceev |
m/min |
32 |
|
|
Max. pub ceev |
m/min |
60 |
|
|
Mob stroke |
mm |
7000 |
|
|
Sab saum toj tsav |
Max. lub zog |
N.m |
14500/7250 |
|
Max. ceev |
r / min |
75/150 |
|
|
I.D |
mm |
φ55 |
|
|
Deck cav |
Hom |
YC6J210-T300 |
|
|
Rated zog |
kW |
154 |
|
|
cuab yeej winch |
Hoisting muaj peev xwm |
kN kev |
30 |
|
Breakout ntaus ntawv |
Max. tawg torque |
N.m |
32000 |
|
cev av nkos |
I.D |
mm |
- |
|
Max. siab |
MPa |
4 |
|
|
Chassis |
Qhov ceev tshaj plaws |
km/h |
3 |
|
Max. nce toj gradient |
% |
39 |
|
|
Max. av clearance ntawm crawler |
- hli |
1300 |
|
|
Max. sab hauv nruab nrab ntawm cov ceg txhawb nqa pem hauv ntej |
mm |
2900 |
|
|
Max. iner dstance nruab nrab ntawm nraub qaum txhawb ob txhais ceg |
mm |
2700 |
|
|
Ua hauj lwm dimension |
mm |
5100*3200*9800 |
|
|
Kev thauj mus los dimension |
mm |
62100*2100*2690 |
|
|
Qhov hnyav |
t |
12 |
|
Khoom nthuav dav
- Hom Lub Npe: D miningwell
- Ntawv pov thawj: CE, ISO
- Yam tsawg kawg nkaus Order Quantity: 1 Set
- Ntim Cov Lus Qhia: 40FR / Bulk Carrier
- Lub sij hawm xa tuaj: 30-45 Hnub
- Cov nqe lus them nqi: L / C, T / T, Western Union
Cav thiab Fais fab Unit
Tsim los ntawm Cummins Suav III-theem cav, MW7╱360BⅨ hydraulic drilling rig boasts advanced hluav taws xob-tswj txhaj tshuaj tshuab. Cov txheej txheem no txhim kho roj efficiency, txo qis emissions, thiab ua kom ib puag ncig sustainability. Lub tshuab ntse tswj qhov system txo cov teeb meem xws li kev hloov pauv ceev thiab cov pa luam yeeb dawb thaum muab cov lej tsis siv neeg tsis siv neeg tso rau kev saib xyuas yooj yim.
Lub zog hydraulic tag nrho ua kom ntseeg tau qhov kev ua tau zoo, nrog lub peev xwm loj ntawm lub hauv paus axis los txhim kho lub peev xwm thauj khoom thiab drilling precision. Ntau cov ntsaws ruaj ruaj tau lees tias muaj kev sib khi ruaj khov, ua kom lub cev muaj sia nyob thiab txo cov kev tu ncua.
Advanced Mast thiab Drilling Capabilities
Lub tsheb no mounted drilling rig nta ib tug loj-stroke retractable mast tsim los haum rau 6-meter casing kav, ua rau nws haum rau tob thiab complex drilling tej yaam num. Adjustable-interval zawv zawg blocks ntawm cov mast sab hauv thiab sab nrauv txo qis hnav thiab tu nqi. Lub mast lub thawv qauv yog heev resistant rau torsion thiab qaug zog, muab superior durability txawm nyob rau hauv ib puag ncig nyuaj.
Lub thib rau-tiam Kelly bar, ua nrog cov ntaub ntawv kho dua tshiab thiab ntxiv dag zog thaiv cov nplhaib, txhim kho lub zog thiab ua kom muaj txiaj ntsig zoo hauv cov txheej pob zeb uas muaj zog heev.
Intelligent thiab Versatile Design
Lub portable zoo drilling rig hydraulic MW7╱360BⅨ suav nrog kev txawj ntse hloov kho kom pom kev ua haujlwm zoo. Nws hydraulic sab saum toj tsav system tso cai rau siab drilling ceev thiab efficiency, haum rau ntau yam drilling txoj kev, xws li av nkos, huab cua, thiab ua npuas ncauj drilling. Lub rig yog txawm peem rau nrog ib tug visualised siab system rau precision pressurization thiab decompression pub, ua kom zoo kho raws li qhov tob drilling.
Mobility thiab Application Range
Mounted ntawm lub tsheb thauj khoom hloov tau yooj yim, MW7╱360BⅨ hydraulic dej zoo drilling rig navigates nyuaj struts nrog yooj yim, kom ntseeg tau nkag mus rau tej thaj chaw deb thiab rugged drilling qhov chaw. Nws cov ntawv thov dav suav nrog cov dej dej hauv dej, coalbed methane extraction, tshawb nrhiav hauv ntiaj teb, ntiav shale gas drilling, thee mining, thiab kev ua haujlwm thaum muaj xwm txheej ceev.
Daim ntawv thov
Nrog nws cov hydraulic system muaj zog, qhov loj-inch sab saum toj-mounted tsav spindle, thiab kev tsim kho siab heev, MW7╱360BⅨ teeb tsa tus qauv hauv portable hydraulic drilling rigs, nws versatility thiab adaptability rau ntau haiv neeg siv technologies, xws li cua DTH rauj drilling thiab av nkos drilling. , ua kom nws yog qhov kev xaiv zoo tshaj plaws rau cov kws tshaj lij nrhiav kev ua haujlwm zoo thiab kev ntseeg siab hauv qhov dej tob tob tob..
Shipping & Them Nyiaj
Txhua daim ntawm Miningwell tsheb mounted borehole drilling rig undergoes ib tug nruj load ruaj ntseg xyuas kom muaj kev ruaj ntseg ntawm lub cargo nyob rau hauv lub thawv.
Peb txoj kev them nyiaj: credit card, L / C, T / T, Western Union, thiab peb txhawb nqa shipping los ntawm huab cua thiab hiav txwv.
