Specifications
|
Qauv |
DHD 340 |
DHD 350 |
DHD 360 |
DHD 380 |
|
Ntev (Lessbit) |
10 32mm |
1 209mm |
1 063mm |
1 492mm |
|
Qhov hnyav (Lessbit) |
43kg ua |
7 8,5kg |
100.5 Kg |
190kg ib |
|
Sab nraud txoj kab uas hla |
99mm ua |
125 hli |
142mm ib |
180 hli |
|
Qhov Loj |
φ{0}} hli |
φ{0}} hli |
φ{0}} hli |
φ{0}} hli |
|
Kev sib txuas xov |
API2 3/8"REG |
API2 3/8"REG |
API3 1/2"REG |
API4 1/2"REG |
|
Ua Haujlwm Siab |
1 0-2.2MPa |
1.0-2.5MPa |
1.0-2.5MPa |
1.5-3.3MPa |
|
Pom zoo rotation ceev |
30-60 r/min |
30-60 r/min |
30-60 r/min |
30-60 r/min |
|
Kev siv cua |
5.5 m³ / min (1. 0MPa) |
9 m³ / min (1. 0MPa) |
2 0m³/min (1.0MPa) |
26m³ / min (1.8MPa) |
|
10m³ / min (1.8MPa) |
15m³ / min (1.8MPa) |
28m³ / min (1.8MPa) |
34m³ / min (2.4MPa) |
|
|
Yam khoom |
Qhov hnyav (kg) |
|||
|
Top sub |
8.8 |
14.7 |
20.3 |
42 |
|
"O" Ring |
0.01 |
0.02 |
0.02 |
0.02 |
|
Kuaj Valve |
0.46 |
1 |
0.8 |
1.3 |
|
Caij nplooj ntoos hlav |
0.04 |
0.06 |
0.05 |
0.09 |
|
Rubber Buffer |
0.2 |
0.06 |
0.3 |
0.4 |
|
Valve Rooj |
2.1 |
4.2 |
5 |
13 |
|
Sab hauv lub tog raj kheej |
2.45 |
4.9 |
4 |
9.1 |
|
Piston |
9 |
15.5 |
23.5 |
41.5 |
|
Piston Case |
159 |
30.3 |
37.2 |
62.5 |
|
Ntiv nplhaib Retainer |
0.2 |
0.3 |
0.6 |
1.2 |
|
Tsav Chuckk |
3.7 |
7.1 |
6 |
18.2 |
|
Adjuster Nplhaib |
/ |
0.1 |
/ |
0.2 |
|
Nplhaib xauv |
/ |
0.2 |
/ |
/ |
|
adjuster Xim |
/ |
/ |
/ |
0.2 |
|
Lub tes tsho coj |
/ |
/ |
2.5 |
/ |
Khoom nthuav dav
Lub laum teb, lub tshuab cua compressor thiab "DTH laum hlua", uas ib txwm muaj DTH Drill Rod, DTH rauj thiab DTH Drill Bit, yog cov hauv paus ntawm DTH drilling. D Miningwell DHD siab siab qhov rauj drilling yog siv ntau yam kev siv xws li, tab sis tsis txwv rau, kev tsim kho hnyav, tsuas, roj thiab roj, quarries thiab dej qhov dej.
Qhov zoo
1) Zam cov teeb meem uas tshwm sim hauv qab valve. Fracture, expansion thiab contraction.
2) Tsawg cua siv thiab muaj kev cuam tshuam ntau zaus. 15-30% ntau dua drilling efficiency tshaj qhov xyaum nrog hauv qab valve.
3) Cov qauv yooj yim, cov khoom seem tsawg dua, kev saib xyuas yooj yim dua thiab pheej yig dua.
4) Thaum tshav kub kub-hardened spare qhov chaw, kev pab lub neej ntev thiab tsis ua hauj lwm.
5) Sab saum toj sib koom thiab tsav chuck yog threaded, yooj yim rau disassemble.
Shipping & Them Nyiaj
Txhua daim ntawm Miningwell cov cuab yeej thiab cov khoom siv drilling tau dhau los ua kev kuaj xyuas kev nyab xeeb kom ruaj ntseg ntawm cov khoom thauj hauv lub thawv.
Peb txoj kev them nyiaj: credit card, L / C, T / T, Western Union, thiab peb txhawb nqa shipping los ntawm huab cua thiab hiav txwv.
