Xaiv qhov tsis ncaj ncees lawm huab cua compressor yog ib qho ntawm feem ntau yog vim li casTsawg drilling efficiency, nquag DTH rauj teeb meem, thiab kev siv roj siabnyob rau hauv dej zoo drilling tej yaam num.
Ntau tus neeg yuav khoom tsom ua ntejhom lossis tus nqi, tab sis nyob rau hauv DTH tiag tiag (Down-Lub-Qhov) dej qhov dej drilling, kev ua tau zoo nyob ntawm ntau yam ntawm:
Ua haujlwm siab (bar / psi)
Cua ntws (m³ / min / CFM)
Kev sib txuam nrog DTH rauj loj thiab qhov tob tob
Hauv phau ntawv qhia no, peb piav qhiaYuav ua li cas xaiv qhov zoo cua compressor rau DTH dej zoo drilling, thiab kom meej sib pivAtlas Copco, Chigo, thiab Tuam Tshoj txhim khu kev qha - ua lwm txoj hauv kevraws li cov ntawv thov drilling tiag.
Rau DTH dej zoo drilling:
Cua siab txiav txim siab tob npaum li cas koj tuaj yeem xyaum.
Cua ntws txiav txim siab ceev npaum li cas koj tuaj yeem xyaum.
Txawm hais tias koj xaiv hom hom twg, yog tias lub siab thiab huab cua ntws tsis zoo sib xws, kev ua haujlwm drilling yuav poob qis.
Pom zoo Cua Siab los ntawm Drilling Condition
| Drilling condition | Pom zoo siab |
|---|---|
| Sab saum toj rauj / ntiav drilling | 8-10 bar |
| Txheem DTH drilling (100-150 m) | 14-15 bar |
| Qhov dej tob tob (150-300 m) | 16-18 bar |
| Pob zeb nyuaj lossis qhov tob (300 m +) | 20-25 bar |
Qhov no yog vim li cas ntau qhov dej hauv qhov dej drilling ua haujlwm tsis ncav cuag qhov xav tau qhov tob thaum siv qis - compressors siab.
2. Sib piv cov Cua Compressor nrog DTH Rauj Loj
DTH rauj tsis tuaj yeem ua haujlwm zoo yog tias lub tshuab cua compressor tsis zoo.
Hauv qab no yog cov lus qhia sib piv dav dav siv hauv cov dej zoo drilling dej num:
| DTH Rauj Loj | Yuav tsum muaj siab | Yuav tsum tau Air Flow |
| 3" – 4" | 14-15 bar | 10-14 m³ / min |
| 4" – 5" | 15-17 hli | 14-20 m³ / min |
| 5" – 6" | 17-20 bar | 20-28 m³ / min |
| 6" – 8" | 20-25 bar | 28-35 m³ / min |
Daim ntawv tseem ceeb:Xaiv lub compressor nkaus xwb raws li lub siab, tsis muaj cua txaus, yuav ua rautsawg nkag mus, overheating ntawm rauj, thiab shortened kev pab cuam lub neej.
3. Atlas Copco vs Chigo vs Tuam Tshoj-Ua Compressors
Tsis muaj ib qho "zoo tshaj" hom rau txhua qhov haujlwm drilling. Txoj kev xaiv yog nyob ntawmqhov project scale, drilling qhov tob, txij nkawm tej yam kev mob, thiab pob nyiaj siv.
Atlas Copco Cua Compressors
Atlas Copco compressors paub txog:
High- ua haujlwm huab cua kawg
Kev ua tau zoo heev stability
Lub neej ua haujlwm ntev hauv kev xav tau
Lawv feem ntau xaiv rau:
Loj - nplai mining lossis drilling cov neeg cog lus
Ntev - lub sij hawm txuas ntxiv drilling tej yaam num
Cov neeg siv khoom muaj peev xwm saib xyuas muaj zog thiab muaj peev xwm txaus
Txawm li cas los xij, lubthawj tus nqi yuav khoom thiab cov khoom seem yog tus nqi siab, uas tej zaum yuav tsis haum rau tag nrho cov dej zoo drilling cov neeg ua haujlwm.
Chigo Diesel Ntsia Hlau Cua Compressors
Chigo compressorsyog dav siv nyob rau hauv dej zoo drilling vim hais tias lawv muaj ib tugKev sib xyaw ua ke ntawm kev ua tau zoo, kev ntseeg siab, thiab kev siv nyiaj txiag.
Cov txiaj ntsig tseem ceeb muaj xws li:
Ruaj khov cua siab tso zis rau DTH drilling
Kev sib npaug zoo ntawm kev siv roj thiab kev ua haujlwm drilling
Kev saib xyuas yooj yim dua thiab muaj cov khoom seem sai dua
Hauv kev siv tiag tiag,14.5 bar, 15 bar, thiab 17 bar Chigo qauvfeem ntau txuam nrog4"-5" DTH rauj, ua rau lawv zoo tagnrho rau feem ntau cov dej zoo drilling tej yaam num ntawm 100-300 meters.
Txhim khu Suav teb -Made Alternatives
Nyob rau hauv xyoo tas los no, qee lub Tuam Tshoj - ua diesel ntsia hlau cua compressors tau ua pov thawj ntseeg tau rau:
Me me mus rau nruab nrab drilling neeg cog lus
Export kev lag luam nrog cov kev pab cuam tsawg
Cov phiaj xwm tsom rau kev tswj tus nqi
Qhov tseem ceeb yograug txuam thiab tswj kom zoo, tsis yog lub teb chaws ntawm keeb kwm. Thaum xaiv kom raug, cov compressors tuaj yeem xa cov kev ua haujlwm ruaj khov rau cov dej zoo drilling.
Xaiv lub tshuab cua compressor tsis haum feem ntau ua rau:
Feem ntau DTH rauj jamming
Tsawg drilling nkag tus nqi
Kev siv roj av ntau dhau
Shortened kev pab cuam lub neej ntawm rauj thiab laum khoom
Nce downtime thiab cov nqi khiav hauj lwm siab dua
Feem ntau, cov teeb meem no tau raug liam txhaum rau ntawm qhov drilling rig lossis rauj, thaum qhov teeb meem tiag tiagkev xaiv compressor tsis raug.
Ua ntej xaiv lub tshuab cua compressor, nco ntsoov paub meej tias:
Lub hom phiaj drilling qhov tob
Pob zeb tsim (mos, nruab nrab, nyuaj pob zeb)
DTH rauj loj
Txawm hais tias koj twb muaj lub pob zeb drilling los yog tab tom yuav ib lub tshuab drilling tag nrho
Lub compressor zoo sib xws yuav ua kom zoo dua drilling efficiency thiab txo tag nrho cov nqi khiav lag luam.
Cov ntaub ntawv:Xaiv Txoj Cai Cua Compressor Rau DTH Dej Drilling
6. Tsis paub meej tias Compressor twg haum rau koj qhov DTH Dej Drilling?
Txhawm rau pom zoo rau lub tshuab cua compressor, peb feem ntau xav tau:
Drilling qhov tob
Pob zeb tsim
DTH rauj loj
Cov qauv drilling rig uas twb muaj lawm (yog tias muaj)
Xa cov ntaub ntawv no rau peb, thiab peb yuav phim cov cua compressor zoo tshaj plaws rau koj qhov project drilling hauv 12 teev.
Qhov no ua kom koj lub DTH drilling system ua haujlwm tau zoo, ntseeg tau, thiab kev lag luam.
